1-5
SPECIFICATIONS AND OPERATING REQUIREMENTS
Dynamometer Specifications and Requirements
Version 2 Above Ground Model 200iX/250iX Motorcycle Dynamometer Installation Guide
DYNAMOMETER SPECIFICATIONS AND REQUIREMENTS
The following specifications and requirements will help you set up your dyno area and
verify you have the requirements to operate your dyno safely.
BATTERY REQUIREMENTS
Your 200iX/250iX dyno is designed to carry a group 24 deep-cycle discharge series
battery for operating the starter, power carriage, and optional wheel clamp. The
typical dimensions for this series of batteries are 27 cm long by 17 cm wide by 23 cm
tall (10.625-inches by 6.75-inches by 9.125-inches). The mounting is flexible so a
battery that has dimensions close to this will work satisfactorily. The built-in battery
cables are configured for top-post batteries. This battery is not included with your
dyno. You will need to provide this battery. For more information on installing the
battery, refer to “Battery” on page 2-13.
CHASSIS SPECIFICATIONS
description specifications
Length
with standard carriage allow 271.78 cm (107.00 in.)
with extended carriage allow 322.58 cm (127.00 in.)
with ramp 370.84 cm (146.00 in.)
Height
to top of dyno cover 45.97 cm (18.00 in.)
Width
model 200iX 200.69 cm (79.00 in.)
model 250iX 274.32 cm (108.00 in.)
Weight
model 200i dyno/crated dyno 725 kg (1600 pounds)/771 kg (1700 pounds)
model 250i retarder module/crated 953 kg (2100 pounds)/1,089 kg (2400 pounds)
200iX/250iX drum module/crated 136 kg (300 pounds)/363 kg (800 pounds)
Drum
diameter 45.72 cm (18.00 in.)
width 50.80 cm (20.00 in.)
diameter, 200iX/250iX 45.72 cm (18.00 in.)
width, 200iX/250iX 55.88 cm (22.00 in.)
Frame structural steel
Maximum Speed 322 KPH (200 MPH)
Maximum Motorcycle Length (front of front
wheel to center of rear wheel)
standard carriage 213.00 cm (84.00 in.)
extended carriage 256.54 cm (101.00 in.)
Remote Switches remote software control
