Dynojet 200iX User Manual

E-1
Above Ground Model 200iX/250iX Motorcycle Dynamometer Installation Guide
APPENDIX E
A BOVE G ROUND I XW I NSTALLATION
The above ground model 250iXW Dynojet dynamometer provides the ultimate in
powersports dyno tuning and testing capability. With 73-inch total drum width, and
extra drum and sliding carriage, the 250iXW can handle UTV's, ATV's, karts, trikes,
and motorcycles.
This chapter will walk you through unpacking and installing the above ground iXW
drum module and related items. To ensure safety and accuracy in the procedures,
perform the procedures as they are described.
This Appendix is divided into the following categories:
• Dynamometer Specifications—Above Ground iXW Dyno, page E-2
• Above Ground iXW Upgrade Installation, page E-5
• Side and Top Covers—Above Ground iXW Dyno, page E-14
• Ground Hook Installation—Above Ground iXW Dyno, page E-18
