CHAPTER 3
Air Brake
Above Ground Model 200iX/250iX Mot
orc
ycle D
ynamometer Inst
alla
tion Guide
3-8
5
Secure the switch body to th
e control panel usin
g the switch body nut removed
earlier.
Figure 3-8: Replacing the Emergency Stop Button
6
Secure the Button board to t
he control panel using the fou
r screws removed
earlier.
Figure 3-9: Securing the Button Board
CP033
switch body
switch body nut
control panel
CP032
button board
screw
93
95
