Eaton SmartWire-DT SWD Series User Manual

4 PKE-SWD-32, interface for motor-starter combination with PKE PKE12/32
4.9 Programming
114 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com
4.9.1.8 Type of trip block (TYPE)
The modular design of the PKE electronic motor-protective circuit-breaker
enables several different current ranges to be covered. A different PKE trip
block is inserted into the PKE basic device depending on the current range
required. The following trip blocks of the type “Advanced” can be combined
with the two PKE basic devices PKE12 and PKE32.
Table 12: Combination options of the PKE basic device with PKE trip block
The type of PKE trip block is mapped via the TYPE bit field (input byte 4,
Bit 0 - 2). The values of this bit field are assigned to the following PKE trip
blocks:
Table 13: Bit field Type of trip block
4.9.1.9 Time delay setting (CLASS)
The CLASS bit field shows the value of the setting dial on the PKE trip block
for the time lag class of the overload release. The setting points of the time
lag class dial are assigned to the following values of the CLASS bit field.
Table 14: Bit field Time delay setting (CLASS)
￫
If the communication module PKE-SWD-32 is commissioned
(i.e. by removing and replugging the SWD device connector on
the PKE-SWD-32) while the thermal motor image of the PKE
motor-protective circuit-breaker has the value 100 % or higher,
the contactor is not operational until the value is below the
100 % mark of the thermal image.
Base device PKE-XTUA-1,2 PKE-XTUA-4 PKE-XTUA-12 PKE-XTUA-32
PKE12 ✓ ✓ ✓ X
PKE32
X X ✓ ✓
Field
Value Control option part no.
TYPE 0x0 PKE-XTUA-1,2
0x1 PKE-XTUA-4
0x2 PKE-XTUA-12
0x3 PKE-XTUA-32
0x4 Not defined
0x5 Not defined
0x6 Not defined
0x7 Not defined
￫
The TYPE bit field can likewise be read as an acyclical data
object
(￫ Section 4.9.4, "Acyclic data", page 121).
