13 Appendix
13.4 Color tables M22-SWD-LED(C)-RGB
SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com 257
13.4 Color tables M22-SWD-LED(C)-RGB
13.4.1 Color table profile 1
13.4.2 Color table profile 2...5
Index Color (RGB) Flashing ?Frequency
0 LED off - -
1
Red (200, 0, 0) - -
2
Green (0, 200, 0) - -
3
Yellow (100, 100, 0) - -
4
Blue (0, 0, 200) - -
5
Green (0, 200, 0) 50/50 % 1 Hz
6
White (70, 70, 70) - -
7
Red (200, 0, 0) 50/50 % 1 Hz
Index Color (R, G, B)
Defined in ROM 0 White (70, 70, 70)
1 Red (200, 0, 0)
2 Green (0, 200, 0)
3 Yellow (100, 100, 0)
4 Blue (0, 0, 200)
5 Magenta (100, 0, 100)
6 Cyan (0, 100, 100)
Predefined colors in ROM
7 undefined
…
43
20 user-defined colors programmed by
Eaton
44
…
63
16 colors in RAM with acyclical Smart-
Wire-DT service "1"
64 Color table is
defined in
SWD-Assist
…
79
