Eaton SmartWire-DT SWD Series User Manual

13 Appendix
13.7 Technical data
SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com 271
13.7.4 DIL contactor modules
DIL-SWD-32-001 DIL-SWD-32-002
General
Standards IEC/EN 61131-2, EN 50178,
IEC/EN 60947
Dimensions W x H x D mm
45 x 38 x 76 45 x 38 x 76
Weight kg
0.04 0.04
Mounting
on DILM7 - DILM38
Mounting position
as DILM7 - DILM38
Ambient mechanical conditions
Degree of protection (IEC/EN 60529, EN50178, VBG 4) IP20 IP20
Vibrations (IEC/EN 61131-2:2008)
Constant amplitude 3.5 mm Hz 5 - 8.4 5 - 8.4
Constant acceleration, 1 g Hz
8.4 - 150 8.4 - 150
Mechanical shock resistance (IEC/EN 60068-
2-27)
semi-sinusoidal 15 g/11 ms
Impact
resis-
tances
9 9
Drop to IEC/EN 60068-2-31 Drop
height
mm
50 50
Free fall, packaged (IEC/EN 60068-2-32) m
0.3 0.3
Electromagnetic compatibility (EMC)
Overvoltage category II II
pollution degree
2 2
Electrostatic discharge (IEC/EN 61131-2:2008)
Air discharge (Level 3) kV 8 8
Contact discharge (Level 2) kV
4 4
Electromagnetic fields (IEC/EN 61131-2:2008)
80 - 1000 MHz V/m 10 10
1.4 - 2 GHz V/m
3 3
2 - 2.7 GHz V/m
1 1
Radio interference suppression (SmartWire-DT)
EN 55011 Class A EN 55011 Class A
Burst (IEC/EN 61131-2:2008, Level 3)
CAN/DP bus cable kV 1 1
SmartWire-DT cables kV
1 1
Radiated RFI
(IEC/EN 61131-2:2008, Level 3)
10 10
Ambient climatic conditions
Operating ambient temperature (IEC 60068-2) °C -25 up to +60 -25 up to +60
Condensation
Must be prevented with suitable measures
Storage °C
-30 up to +70 -30 up to +70
Relative humidity, non-condensing
(IEC/EN 60068-2-30)
%
5 - 95 5 - 95
SmartWire-DT network
Module type SmartWire-DT module (slave)
Baud rate setting
Automatic
Status SmartWire-DT LED
green/orange
Porting
Plug, 8-pole
Plug connector
External device plug SWD4-8SF2-5
Device supply voltage
SWD module
U
SWD
V DC, (%) 14.5 (±3)
Current consumption at U
SWD
￫ Page 253
Operating mode
