13 Appendix
13.7 Technical data
272 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com
Manual/automatic mode no Yes
Setting
– Rotary switches
Connection auxiliary contact
Qty. 2 2
Rated voltage
1)
U
e
V DC 15 15
Input current for state 1, typical mA
3 3
Potential separation
no no
Cable length m
≦ 2.8 ≦ 2.8
Connection type
Push-In Push-In
Terminal capacities
solid
mm2
0.2 - 1.5 (AWG24 - AWG16)
flexible with ferrule
2) mm2
0.25 - 1.5 0.25 - 1.5
Notes 1) own supply
2) Minimum length 8 mm
DIL-SWD-32-001 DIL-SWD-32-002
