Eaton SmartWire-DT SWD Series User Manual

0 About this manual
0.2 SmartWire-DT system overview
10 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com
0.2 SmartWire-DT system overview
The SmartWire-DT communication system is an intelligent bus system and
makes possible the reliable and easy connection of switching devices, pilot
devices and I/O components with overriding bus systems. The components
that are connected with the SmartWire-DT system are linked, e.g. to PROFI-
BUS-DP or CANopen communication networks via gateways.
The SmartWire-DT system makes it possible to connect up to 99 modules to
a SmartWire-DT line.
These modules can be SmartWire-DT modules used to connect DIL contac-
tors, PKE motor-protective circuit-breakers and motor starters, DS7 soft
starters, field bus modules, and NZM circuit-breakers, as well as SmartWire-
DT I/O modules, SmartWire-DT RMQ modules, and base modules for signal
towers.
The electrical connection is effected via a special 8 pole connecting cable and
the relevant plugs.
0.2.1 SWD-Assist
The SmartWire-DT planning and ordering program (SWD-Assist) can be
extremely useful when planning and configuring a SWD line in terms of hard-
ware and software.
SWD Assist provides support in selecting and configuring the various SWD
components and the SWD network.
The SWD-Assist planning program has the current consumption specifica-
tions for all SmartWire-DT modules. During planning, it will automatically cal-
culate and display the corresponding system's current consumption.
The latest version, which features all currently supported SWD modules, can
be downloaded by using the integrated update function in SWD-Assist or
directly from the Eaton Download Center:
01/2020 155 ff M22-SWD-LED(C)-RGB added to Chapter “Pilot devices
M22-SWD…”
✓
157 Multi-color indicator light added to Chapter “M22-SWD-
LED(C)-RGB”
✓
257 Multi-color indicator light added to Chapter “Color tables
M22-SWD-LED(C)-RGB”
✓
160 Chapter “Encoders M22-SWD-INC” parameter configu-
ration modified
✓✓
Publica-
tion date
Page Keyword New Modifi-
cation
