Eaton SmartWire-DT SWD Series User Manual

13 Appendix
13.5 Reference table: Part no., SmartWire-DT vs. Eaton catalog number
258 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com
13.5 Reference table: Part no., SmartWire-DT vs. Eaton catalog number
Type designation Eaton catalog number
DILM7(C)-…(24VDC) XTCE(C)007B…TD
DILM9(C)-…(24VDC)
XTCE(C)009B…TD
DILM12(C)-…(24VDC)
XTCE(C)012B…TD
DILM15(C)-…(24VDC)
XTCE(C)015B…TD
DILM17(C)-…(24VDC)
XTCE(C)017C…TD
DILM25(C)-…(24VDC)
XTCE(C)025C…TD
DILM32(C)-…(24VDC)
XTCE(C)032C…TD
DILM38(C)-…(24VDC)
XTCE038C…TD
contactor relay
DILA(C)-…(24VDC) XTRE(C)10B…TD
Motor-Protective Circuit-Breakers
PKZM0 XTPR…BC1(NL)
PKE12
XTPE012B(NL)
PKE32
XTPE032B(NL)
PKE65
XTPE065B(NL)
PKE-XTUA-1,2
XTPEXTA1P2B
PKE-XTUA-4
XTPEXTA004B
PKE-XTUA-12
XTPEXTA012B
PKE-XTUA-32
XTPEXTA032B
PKE-XTUWA-32
XTPEXTA032D
PKE-XTUA-65
XTPEXTA065D
PKE-XTUACP-36
XTPEXTAO36BD
PKE-XTUWACP-36
XTPEXTAO36DD
PKE-XTUACP-65
XTPEXTAO65DD
Accessories for motor-protective
circuit-breaker
NHI-E-…-PKZ0 XTPAXFA…
NHI-…-PKZ0
XTPAXSA…
AGM2-…-PKZ0
XTPAXSATR…
Electronic motor starter
EMS-DO-T-2.4-SWD-ADP EMS-DO-T-2P4-SWD-ADP
EMS-RO-T-2.4-SWD-ADP
EMS-RO-T-2P4-SWD-ADP
Motor-starter combination
MSC-D-…(24VDC) XTSE…TD…
MSC-DEA-…(24VDC)
XTNE…TD…
Wiring set
DILM12-XRL XTCEXRLB
DILM12-XP2
XTCEXPBB
DILM12-XR
XTCEXRBB-OA2
DILM12-XEV
XTCEXLBB
DILM32-XRL
XTCEXRLC
PKZM0-XRM12
XTPAXTPCRB
