13 Appendix
13.1 Maximum current consumption of SmartWire-DT modules on U
SWD
SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com 253
13 Appendix
13.1 Maximum current consumption of SmartWire-DT modules on U
SWD
Catalog number Article no. Current consumption
[mA]
Notes
M22-SWD-INC 179982 10 –
M22-SWD-K11 115964
10
M22-SWD-K22 115965 10 –
M22-SWD-LED-W 115966
22 –
M22-SWD-LED-B 115967
22 –
M22-SWD-LED-G 115968
22 –
M22-SWD-LED-R 115969
22 –
M22-SWD-K11LED-W 115972
22 –
M22-SWD-K11LED-B 115973
22 –
M22-SWD-K11LED-G 115974
22 –
M22-SWD-K11LED-R 115975
22 –
M22-SWD-K22LED-W 115978
22 –
M22-SWD-K22LED-B 115979
22 –
M22-SWD-K22LED-G 115980
22 –
M22-SWD-K22LED-R 115981
22 –
M22-SWD-NOP 147637
10 –
M22-SWD-KC11 115995
10 –
M22-SWD-KC22 115996
10 –
M22-SWD-LEDC-W 115997
22 –
M22-SWD-LEDC-B 115998
22 –
M22-SWD-LEDC-G 115999
22 –
M22-SWD-LEDC-R 116000
22 –
M22-SWD-K11LEDC-W 116003
22 –
M22-SWD-K11LEDC-B 116004
22 –
M22-SWD-K11LEDC-G 116005
22 –
M22-SWD-K11LEDC-R 116006
22 –
M22-SWD-K22LEDC-W 116009
22 –
M22-SWD-K22LEDC-B 116010
22 –
M22-SWD-K22LEDC-G 116011
22 –
M22-SWD-K22LEDC-R 116012
22 –
M22-SWD-NOPC 147638
10 –
M22-SWD-R 179293
10 –
DIL-SWD-32-001 118560
40 –
DIL-SWD-32-002 118561
40 –
PKE-SWD 150613, 150614
35 –
PKE-SWD-32 126895
58 –
PKE-SWD-CP 172735
35 –
NZM-XSWD-704 135530
35 –
EMS-DO-T-2.4-SWD-ADP 172760
22 –
EMS-DO-T-9-SWD-ADP 172762
22 –
EMS-RO-T-2.4-SWD-ADP 172761
22 –
EMS-RO-T-9-SWD-ADP 172763
22 –
EU5E-SWD-8DX 116381
16 –
EU5E-SWD-4DX 144060
33 –
EU5E-SWD-4D4D, ...-R 116382, 191941
33 –
EU5E-SWD-4D2R 116383
45 –
EU5E-SWD-X8D 144061
43 –
EU5E-SWD-4AX 144062
22 –
EU5E-SWD-2A2A 144063
22 –
EU5E-SWD-4PT 144064
22 –
EU5E-SWD-4PT-2 172560
22 –
M22-SWD-I1-LP01 115990
17 with bus termination
resistor switched on
M22-SWD-I2-LP01 115991
17
M22-SWD-I3-LP01 115992
17
M22-SWD-I4-LP01 115993
17
M22-SWD-I6-LP01 115994
17
