Eaton SmartWire-DT SWD Series User Manual

13 Appendix
13.7 Technical data
278 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com
13.7.7 Bus termination resistor, switch cabinet leadthroughs
SWD4-RC8-10 SWD4-SFL8-20 SWD4-SML8-20
General
Standards IEC/EN 61131-2, EN 50178
Dimensions W x H x D mm
48.5 x 34.5 x 10 35 x 83 x 40 35 x 83 x 46
Weight g
10 50 50
Mounting position
Any Any Any
Ambient mechanical conditions
Degree of protection (IEC/EN 60529,
EN50178, VBG 4)
IP20 IP67 IP67
Vibrations (IEC/EN 61131-2:2008)
Constant amplitude 3.5 mm Hz 5 - 8.4 5 - 8.4 5 - 8.4
Constant acceleration, 1 g Hz
8.4 - 150 8.4 - 150 8.4 - 150
Mechanical shock resistance (IEC/EN 60068-2-
27)
semi-sinusoidal 15 g/11 ms
Impact
resis-
tances
9 9 9
Drop to IEC/EN 60068-2-31 Drop
height
mm
50 – –
Free fall, packaged
(IEC/EN 60068-2-32)
m
0.3 – –
Electromagnetic compatibility (EMC)
Overvoltage category II – –
pollution degree
2 – –
Electrostatic discharge
(IEC/EN 61131-2:2008)
Air discharge (Level 3) kV 8 8 8
Contact discharge (Level 2) kV
4 4 4
Electromagnetic fields
(IEC/EN 61131-2:2008)
80 - 1000 MHz V/m 10 10 10
1.4 - 2 GHz V/m
3 3 3
2 - 2.7 GHz V/m
1 1 1
Radio interference suppression (SmartWire-DT)
EN 55011 Class A – –
Burst (IEC/EN 61131-2:2008, Level 3)
– –
SmartWire-DT cables kV
1 – –
Radiated RFI
(IEC/EN 61131-2:2008, Level 3)
V
10 10 10
Ambient climatic conditions
Ambient temperature
(IEC 60068-2)
°C -25 - +55 -25 - +55 -25 - +55
Condensation
Must be prevented with suitable measures
Storage °C
-40 - +70 -40 - +70 -40 - +70
Relative humidity, no condensation
(IEC/EN 60068-2-30)
%
5 - 95 5 - 95 5 - 95
Connection options
SWD In Socket, 8-pole Plug, 8 pole Plug, 8-pole
Number of insertion cycles
 200  200  500
SWD Out
– Socket, 8 pole Socket, 8-pole
Number of insertion cycles
–  500  200
Current consumption
(15-V-SmartWire-DT supply)
￫ Page 253
