8 SL4-SWD and SL7-SWD base modules for signal towers
8.5 Commissioning
210 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com
8.5 Commissioning
Once all the SmartWire-DT modules are connected to the SWD line, you will
need the SmartWire-DT coordinator to automatically assign addresses to all
of them. To do this, press the configuration button on the front of the Smart-
Wire-DT coordinator.
During the address assignment process, the SmartWire-DT modules' mod-
ule LED will flash. If the process is completed successfully, the module LED
will show a continous green light.
8.5.1 Exchange of modules
After replacing the modules and turning on the voltage, you will have to
press the configuration button. When this is done, the new module will be
assigned an address.
8.5.2 Device status
The individual SmartWire-DT modules indicate their device status with the
help of a module LED.
Table 59: Module LED diagnostic messages
8.6 Parameterization
Depending on the coordinator being used, the module's parameters will
need to be configured in the programming system or in the SWD-Assist plan-
ning and commissioning program.
ACHTUNG
Switch off the entire SmartWire-DT system before replacing
SmartWire-DT base modules.
ACHTUNG
The order of the SmartWire-DT units must not be altered.
Designation Color State Message
Module-LED Green Continuous light Device is operating fault-free.
flashing (1 Hz) • addressing process in progress
• after gateway power On
• after actuation of the configuration button on the
gateway
• Module not in current configuration
• invalid type
AUS no 15 V supply voltage
