6 PKE-SWD-CP, Connection for circuit-breaker PKE
6.3 Engineering
SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com 141
6.3 Engineering
The following PKE trip blocks of the type PKE-XTU(W)ACP-… can be com-
bined with the two PKE basic devices PKE32 and PKE65.
The PKE-SWD-CP module takes the power it uses for its communications
electronics and for driving its LEDs from the SmartWire-DT system's U
SWD
15-V supply voltage.
Take the total power consumption of your SmartWire-DT system into
account. If necessary, add an additional EU5C-SWD-PF2-1 power feeder
module to your configuration.
PKE-XTUACP-32 PKE-XTUWACP-36 PKE-XTUACP-65
PKE32 ✓ X X
PKE65
X ✓ ✓
￫
For data for the current consumption please refer to the table
￫ Chapter 13 “Appendix”, page 253
