5 Connection PKE-SWD for motor-protective circuit-breaker PKE12/32/65
5.10 Programming
SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com 129
5.10 Programming
5.10.1 PKE-SWD cyclical data
The PKE-SWD has a maximum of five input bytes and one output byte.
5.10.1.1 Input points
Byte 0:
Byte 1:
￫
The number of cyclical input bytes can be adjusted by means of
different data profiles of the module (￫ Section 5.10.2, „Data
profiles“, page 136).
76543210
SUBST PRSNT – F – – STAT –
Data bit
Designation Description
0 Not used -
1
STAT Contactor state PKE
0: PKE switched off
1: PKE Powered up
2
Not used -
3
Not used -
4
F = Failure 0: No diagnostic alarm
1: Module signals diagnostics
5
Not used -
6
PRSNT 0: Module not available
1: Module available
7
SUBST 0: Configured module present
1: Universal module M22-SWD-NOP(C) present
76543210
– TRIPR TRIPR TRIPR Ir Ir Ir Ir
Data bit
Designation Description Notes
0-3 Ir Set value I
r
￫ Section 5.10.1.4, „Set value (Ir)“,
page 132
4-6
TRIPR =
Trip reason
Trip Reason ￫ Section 5.10.1.5, „Dierential trip
indication (TRIPR)“, page 133
7
Not used – –
