Eaton SmartWire-DT SWD Series User Manual

5 Connection PKE-SWD for motor-protective circuit-breaker PKE12/32/65
5.10 Programming
132 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com
5.10.1.4 Set value (I
r
)
The overload release value set on the PKE basic device is indicated via bit
field I
r
(input byte 1, bit 0, ..., bit 3). The value of this bit field indicates the
absolute current value of the overload release, which depends on the PKE
trip block selected. Bit field I
r
has the following meaning for the different PKE
trip blocks:
Table 18: Bit array Ir
Field
Value PKE-XTUA-0.3
I
r
[A]
PKE-XTUA-4
I
r
[A]
PKE-XTUA-12
I
r
[A]
PKE-XTU(W)A-32
I
r
[A]
PKE-XTUA-65
I
r
[A]
Ir
0x0 0.30 1.00 3.00 8.00 16.00
0x1 0.33 1.10 3.30 8.80 17.60
0x2 0.36 1.20 3.60 9.70 19.30
0x3 0.40 1.30 4.00 10.50 21.30
0x4 0.43 1.42 4.30 11.50 23.00
0x5 0.47 1.55 4.70 12.50 24.80
0x6 0.50 1.70 5.00 13.50 26.80
0x7 0.56 1.90 5.60 15.00 30.00
0x8 0.63 2.10 6.30 17.00 33.60
0x9 0.70 2.40 7.00 19.00 37.70
0xA 0.77 2.60 7.70 20.50 40.90
0xB 0.83 2.80 8.30 22.00 44.40
0xC 0.90 3.00 9.00 24.00 48.10
0xD 1.00 3.30 10.00 27.00 53.30
0xE 1.10 3.70 11.00 29.00 58.60
0xF 1.20 4.00 12.00 32.00 65.00
