Eaton SmartWire-DT SWD Series User Manual

5 Connection PKE-SWD for motor-protective circuit-breaker PKE12/32/65
5.10 Programming
SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com 131
5.10.1.2 Outputs
Byte 0:
Remote tripping through output bit R_TRIP causes a trip if a phase current of
at least 85 percent of the minimum mark of the variable overload release on
the PKE trip block flows through all three main circuits (for example PKE-
XTUA-4
￫ I
min
= 0.85 × 1A = 0.85 A).
5.10.1.3 Diagnostics
In the event of a diagnosis the module reports the following error causes
(input byte 0, bit 4 is set):
76543210
––––––R-TRIP–
Data bit
Designation Description Notes
1 R-TRIP Remote tripping, PKE basic device
0: no remote tripping
1: Remote tripping
CAUTION.
Signal “Remote tripping of PKE basic device” is supported by
PKE trip blocks of the following or later versions:
PKE-XTUA-1.2/4/12/32 PKE-XTUWA-32 PKE-XTUA-65
Release designation 05 01 01
Value Description Remedy
0x03 No communication between PKE-SWD and
PKE trip block
Check whether the PKE trip block used is of part
no. PKE-XTU(W)A.
