Eaton SmartWire-DT SWD Series - M22-SWD Connections

13 Appendix
13.7 Technical data
SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com 275
13.7.6 M22-SWD connections
M22-SWD-K11/M22-SWD-KC11
M22-SWD-LED-…/M22-SWD-LEDC-…
M22-SWD-K11LED-…/M22-SWD-K11LEDC-…
M22-SWD-K11/
M22-SWD-KC11
M22-SWD-LED-…/
M22-SWD-LEDC-…
M22-SWD-K11LED-…/
M22-SWD-K11LEDC-…
M22-SWD-R
M22-SWD-INC
General
Standards IEC/EN 61131-2, EN 50178
Dimensions W x H x D mm 12 x 42 x 39/
12 x 45 x 37
10 x 42 x 45/
10 x 45 x 42
12 x 42 x 45/
12 x 45 x 42
12 x 42 x 45/
12 x 45 x 42
Weight g
10 10 10 10
Mounting position
Any
Ambient mechanical conditions
Degree of protection (IEC/EN 60529,
EN50178, VBG 4)
IP20 IP20 IP20 IP20
Vibrations
(IEC/EN 61131-2:2008)
Constant amplitude 3.5
mm
Hz 5 5 - 8.4 5 - 8.4 5 - 8.4
Constant acceleration 1 g Hz
8.4 - 150 8.4 - 150 8.4 - 150 8.4 - 150
Mechanical shock resistance
(IEC/EN 60068-2-27)
semi-sinusoidal 15 g/11 ms
Impact
resis-
tances
9 9 9 9
Drop
(IEC/EN 60068-2-31);
drop height
mm
50 50 50 50
Free fall, packaged
(IEC/EN 60068-2-32)
m
0.3 0.3 0.3 0.3
Electromagnetic compatibility (EMC)
Overvoltage category Not Applicable
pollution degree 2 2 2 2
Electrostatic discharge
(IEC/EN 61131-2:2008)
Air discharge (Level 3) kV 8 8 8 8
Contact discharge (Level 2) kV
4 4 4 4
Electromagnetic fields (IEC/EN 61131-
2:2008)
80-1000 MHz V/m 10 10 10 10
1.4 - 2 GHz V/m
3 3 3 3
2 - 2.7 GHz V/m
1 1 1 1
Radio interference suppression (Smart-
Wire-DT)
EN 55011 Class A
Burst (IEC/EN 61131-2:2008, Level 3)
Supply cables kV 2 2 2 2
SmartWire-DT cables kV
1 1 1 1
Radiated RFI
(IEC/EN 61131-2:2008, Level 3)
V
10 10 10 10
Ambient climatic conditions
Operating ambient tempera-
ture (IEC 60068-2)
°C –30 - +55 –30 - +55 –30 - +55 –30 - +55
Condensation
Must be prevented with suitable measures
Storage °C –40 - 80 –40 - 80 –40 - 80 –40 - 80
Relative humidity, non-
condensing (IEC/EN 60068-2-
30)
%
9 - 95 9 - 95 9 - 95 9 - 95
SmartWire-DT network
Module type SmartWire-DT module (slave)
