Eaton SmartWire-DT SWD Series - Coupling, Plug

13 Appendix
13.7 Technical data
280 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com
13.7.9 Coupling, plug
SWD4-8SFF2-5 SWD4-8SF2-5 SWD4-8FRF-10
General
Standards IEC/EN 61131-2, EN 50178
Dimensions W x H x D mm
48.5 x 34.5 x 10 15 x 36.5 x 17.5 35 x 90 x 35
Weight g
4.5 5.5 42
Mounting position
Any Any Any
Ambient mechanical conditions
Degree of protection (IEC/EN 60529, EN50178, VBG 4) IP20 IP20 IP20
Vibrations (IEC/EN 61131-2:2008)
Constant amplitude of 3.5 mm Hz 5 - 8.4 5 - 8.4 5 - 8.4
Constant acceleration 1 g Hz
8.4 - 150 8.4 - 150 8.4 - 150
Mechanical shock resistance (IEC/EN 60068-2-
27)
semi-sinusoidal 15 g/11 ms
Impact
resis-
tances
9 9 9
Electromagnetic compatibility (EMC)
Electrostatic discharge (IEC/EN 61131-2:2008)
Air discharge (Level 3) kV 8 – –
Contact discharge (Level 2) kV
4 – –
Ambient climatic conditions
Operating ambient temperature
(IEC 60068-2)
°C -25 - +55 -25 - +55 -25 - +55
Condensation
Must be prevented with suitable
measures
Storage °C -40 - +70 -40 - +70 -40 - +70
Relative humidity, non-condensing
(IEC/EN 60068-2-30)
%
5 - 95 5 - 95 5 - 95
Connection options
SWD In Plug,
8-pole
Plug connector Plug,
8-pole
Number of insertion cycles
 200 1  200
SWD Out
Plug,
8-pole
Socket,
8-pole
Push in terminals
Number of insertion cycles
 200  200 –
Current consumption (15-V-SmartWire-DT supply)
￫ Page 253
