11 Interface for NZM compact circuit-breakers
11.8 Programming
SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com 245
The following applies to devices belonging to device version 04 or higher:
Program the following logic for every switching operation:
▶ After a switching command, check whether it has been properly carried
out using the appropriate input auxiliary contacts.
▶ If two seconds have passed and the switching command still has not
been carried out successfully, cancel the switching command.
To do this, enter the original state as a switching command.
11.8.2 Decoding CB type and CB identification
A ready-to-use function block is provided since decoding is a complex opera-
tion on account of the range of different NZM types. A special description,
“Decoding CB types and CB identification,” is also provided.
Both can be downloaded from the following internet page:
ftp://ftp.moeller.net/CIRCUIT_BREAKER/KOMMUNIKATION/NZM_XSWD_704/
11.8.2.1 Diagnostics
In the event of a diagnosis the module reports the following error causes
(input byte 0, bit 4 is set):
Value Description Remedy Notes
0x03 No circuit-breaker
connected
• Check the cable connection to the circuit-
breaker.
• If necessary, replace circuit-breaker and
cables.
The digital input and output states
are still transferred in this state.
0x13
Short-circuit on output
Q0 or Q1
• Check wiring of the outputs.
0x14 Internal fault in NZM-
XSWD-704
• Attempt a reset by switching on the power
supply again.
• Exchange the module.
0x16 Power meters invalid • Reset counter value via output command
and observe whether the fault is rectified.
• Replace module as memory is faulty.
A memory error has occurred in the
NZM-XSWD-704.
