Eaton SmartWire-DT SWD Series User Manual

6 PKE-SWD-CP, Connection for circuit-breaker PKE
6.10 Programming
152 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com
6.10.2 Data profiles
The quantity of cyclical input data of the PKE-SWD-CP can be adapted to the
application with different data profiles of the module. The data profiles are
selected in the hardware configuration program/PLC configuration program.
The following four data profiles are available for the PKE-SWD-CP:
Table 31: Data profile for PKE-SWD-CP
Special considerations when using the module with a CANopen field
bus
When using data profile 1, 3 or 4 in conjunction with SmartWire-DT gateway
EU5C-SWD-CAN, entries in the setting range for associated service data
objects (SDO) 2102subx must be changed in the PLC configuration program.
With programming system CoDeSys, for example, change the default value
from 0x2093 to 0x2094 to use PKE profile 3.
In programming systems with a controller configurator without automatic
profile selection for SDO parameterization the corresponding SDO object
2102subx is inserted in the SDO object list and its content transferred when
data profile 1 or 3 is used.
Data
byte 7
Data
byte 6
Data-
byte 5
Data-
byte 4
Data
byte 3
Data
byte 2
Data
byte 1
Data
byte 0
Data profile 1 X X X X X X ✓ ✓
Data profile 2
(default)
X X X X ✓ ✓ ✓ ✓
Data profile 3
X X X ✓ ✓ ✓ ✓ ✓
Data profile 4
✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓
Object 2102subx
(x represents the position of the PKE-
SWD in the SmartWire-DT line)
Contents
Profile 1 0x2091
Profile 2 (default)
0x2093
Profile 3
0x2094
Profile 4
0x2095
￫
Data bytes that are not transferred cyclically in certain profiles
can still be read as acyclical data objects (￫ Section
6.10.3, „Acyclic data PKE-SWD-CP“, page 153).
