Eaton SmartWire-DT SWD Series User Manual

6 PKE-SWD-CP, Connection for circuit-breaker PKE
6.10 Programming
SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com 151
Table 29: Bit array TYPE
6.10.1.9 Short-circuit release (I >) factor
The I > bit field is used to represent the value for the short-circuit release fac-
tor that is set using the setting dial found on the PKE trip block.The short-cir-
cuit release value is yielded by multiplying this factor by the set rated opera-
tional current value. The I > bit field can assume the following values:
Table 30: Bit array I >
Field
Value Control option part no.
TYPE 0x0 Not defined
0x1 PKE-XTUACP-36
0x2 PKE-XTUWACP-36
0x3 PKE-XTUACP-65
0x4 Not defined
0x5 Not defined
0x6 Not defined
0x7 Not defined
￫
The TYPE bit field can likewise be read as an acyclical data
object
(￫ Section 6.10.3, „Acyclic data PKE-SWD-CP“, page
153).
Field Value Short-circuit release factor
I> 0x0 5
0x1 6.5
0x2 8
0x3 Test position
0x4 Not defined
0x5 Not defined
0x6 Not defined
0x7 Not defined
