2.6 Digital module EU5E-SWD-8DX
2.6.1 INTRODUCTION
SmartWire-DT I/O module EU5E-SWD-8DX provides eight digital inputs, with
which various sensors can be integrated into the SmartWire-DT network.
The inputs' status is indicated with the help of LEDs.
The SmartWire-DT diagnostic LED indicates the network status.
2.6.2 Surface mounting
Figure 8: Connections of the module EU5E-SWD-8DX
2.6.3 Engineering
There are no specific engineering notes for this device model.
a
b
c
d
e
a SmartWire-DT cable with external device plug
b SmartWire-DT diagnostics LED
c Status LEDs of the inputs
d I0 – I7 (inputs)
e 0-V connection
