13.3 Data requirement (bytes) SmartWire-DT modules
SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com 255
13.3 Data requirement (bytes) SmartWire-DT modules
SmartWire-DT module Input Output
M22-SWD-INC 3 3
M22-SWD-K11
1 0
M22-SWD-K22
1 0
M22-SWD-LED-W
1 1
M22-SWD-LED-B
1 1
M22-SWD-LED-G
1 1
M22-SWD-LED-R
1 1
M22-SWD-K11LED-W
1 1
M22-SWD-K11LED-B
1 1
M22-SWD-K11LED-G
1 1
M22-SWD-K11LED-R
1 1
M22-SWD-K22LED-W
1 1
M22-SWD-K22LED-B
1 1
M22-SWD-K22LED-G
1 1
M22-SWD-K22LED-R
1 1
M22-SWD-KC11
1 0
M22-SWD-KC22
1 0
M22-SWD-LEDC-W
1 1
M22-SWD-LEDC-B
1 1
M22-SWD-LEDC-G
1 1
M22-SWD-LEDC-R
1 1
M22-SWD-K11LEDC-W
1 1
M22-SWD-K11LEDCnc-B
1 1
M22-SWD-K11LEDC-G
1 1
M22-SWD-K11LEDC-R
1 1
M22-SWD-K22LEDC-W
1 1
M22-SWD-K22LEDC-B
1 1
M22-SWD-K22LEDC-G
1 1
M22-SWD-K22LEDC-R
1 1
M22-SWD-R
3 0
DIL-SWD-32-001
1 1
DIL-SWD-32-002
1 1
PKE-SWD profile 1
2 1
PKE-SWD profile 2
4 1
PKE-SWD profile 3
5 1
PKE-SWD-32 profile 1
2 1
PKE-SWD-32 profile 2
4 1
PKE-SWD-32 profile 3
5 1
PKE-SWD-CP Profile 1
2 1
PKE-SWD-CP Profile 2
4 1
PKE-SWD-CP Profile 3
5 1
PKE-SWD-CP Profile 4
8 1
NZM-XSWD-704 profile 1
3 3
NZM-XSWD-704 profile 2
11 3
NZM-XSWD-704 profile 3
15 3
NZM-XSWD-704 profile 4
31 3
EMS-...-SWD-ADP
1 1
EU5E-SWD-4DX
2 0
EU5E-SWD-8DX
2 0
EU5E-SWD-4D4D, ...-R
1 1
EU5E-SWD-4D2R
1 1
EU5E-SWD-X8D
1 1
EU5E-SWD-4AX
9 0
EU5E-SWD-2A2A
5 4
EU5E-SWD-4PT
9 0
EU5E-SWD-4PT-2
9 0
M22-SWD-I1-LP01
0 0
M22-SWD-I2-LP01
0 0
M22-SWD-I3-LP01
0 0
M22-SWD-I4-LP01
0 0
