5 Connection PKE-SWD for motor-protective circuit-breaker PKE12/32/65
5.10 Programming
130 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com
Byte 2:
Byte 3:
Byte 4:
76543210
I-REL I-REL I-REL I-REL I-REL I-REL I-REL I-REL
Data bit
Designation Description Notes
0-7 I-REL Relative current value ￫ Section 5.10.1.6, „Relative
current value (I-REL)“, page 133
76543210
TH TH TH TH TH TH TH TH
Data bit
Designation Description Notes
0-7 TH Thermal motor image [%] ￫ Section 5.10.1.7, „Thermal
motor image [TH]“, page 134
76543210
– – CLASS CLASS CLASS TYPE TYPE TYPE
Data bit
Designation Description Notes
0-2 TYPE Control option part no. ￫ Section 5.10.1.8, „Type of trip
block (TYPE)“, page 134
3-5
CLASS Set time lag ￫ Section 5.10.1.9, „Time delay
setting (CLASS)“, page 135
6
Not used - -
7
Not used - -
