13 Appendix
13.7 Technical data
SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com 277
Air discharge (Level 3) kV 8 8 8
Contact discharge (Level 2) kV
4 4 4
Electromagnetic fields (IEC/EN 61131-
2:2008)
80-1000 MHz V/m 10 10 10
1.4 - 2 GHz V/m
3 3 3
2 - 2.7 GHz V/m
1 1 1
Radio interference suppression (Smart-
Wire-DT)
Burst (IEC/EN 61131-2:2008, Level 3)
Supply cables kV 2 2 2
SmartWire-DT cables kV
1 1 1
Radiated RFI
(IEC/EN 61131-2:2008, Level 3)
V
10 10 10
Ambient climatic conditions
Operating ambient tempera-
ture (IEC 60068-2)
°C –30 - +55 –30 - +55 –30 - +55
Condensation
Storage °C –40 - 80 –40 - 80 –40 - 80
Relative humidity, non-
condensing (IEC/EN 60068-2-
30)
%
9 - 95 9 - 95 9 - 95
SmartWire-DT network
Module type
Baud rate setting Automatic Automatic Automatic
Status SmartWire-DT LED
Green Green Green
Porting
Plug, 8-pole Plug, 8-pole Plug, 8-pole
Plug connector
SWD4-8SF2-5/
M22-SWD-I…LP
SWD4-8SF2-5/
M22-SWD-I…LP
SWD4-8SF2-5
Number of insertion cycles
50 50 50
Device supply voltage
SWD module U
SWD
V DC, (%) 14.5 (±3)
Current consumption at U
SWD
ï¿« Page 253
Function element
Contacts 2 changeover contacts 2 changeover contacts –
Lifespan mechanical/elec-
trical (operations)
1 x 10
6
1 x 10
6
–
LED indicator
no Yes –
Diagnostics
Yes Yes –
Mounting
Front mount/
base fixing
Front mount/
base fixing
–
M22-SWD-K22/
M22-SWD-KC22
M22-SWD-K22LED-…/
M22-SWD-K22LEDC-…
M22-SWD-NOP(C)
