Eaton SmartWire-DT SWD Series User Manual

13 Appendix
13.7 Technical data
270 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com
Parameter definition (type) – Voltage, current –
Voltage
Output voltage V 0 - 10
maximum output current mA 10
Current
Output current mA 0 - 20
Load resistance O < 500
protected against overload/short-circuit
proof
Yes
Resolution Bit 12
Conversion time ms
Cumulative error % ±1 %
Repeat accuracy ±0.5 %
Temperature inputs
Quantity: two-, three-wire connection, screened,
length < 10 m)
4
Parameterization
Temperature sensor – – Pt100, Pt1000, Ni1000
Scan time/mean-value generation
adjustable adjustable adjustable
Temperature range
Pt100, Pt1000:
°C
– – EU5E-SWD-4PT
-50 up to +200
EU5E-SWD-4PT-2
-100 up to +400
Ni1000:
°C
– – EU5E-SWD-4PT
-50 up to +150
EU5E-SWD-4PT-2
-50 up to +200
Resolution °C
0.1
Look
°C, °F, nonlinear
Conversion time ms
50
Cumulative error %
±1
Repeat accuracy %
±0.5
Potential isolation
Input to SmartWire-DT Yes Yes Yes
Output to SmartWire-DT
Yes
Input to input no no no
Output to input
no
Output to output no
Notes 1) Minimum length 8 mm
EU5E-SWD-4AX EU5E-SWD-2A2A EU5E-SWD-4PT
EU5E-SWD-4PT-2
