Eaton SmartWire-DT SWD Series User Manual

5 Connection PKE-SWD for motor-protective circuit-breaker PKE12/32/65
5.3 Engineering
SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com 125
Where motor-protective circuit-breakers and contactors up to DILM38 are
spatially separated
1)
the contactor can be actuated with SmartWire-DT con-
tactor modules DIL-SWD-32-….
If motor starters with motor-protective circuit-breaker PKE65 and contactors
larger than DILM38 are used, the contactor is actuated through SmartWire-
DT input/output module EU5E-SWD-4D2R. A control voltage other than 24 V
DC can be selected for the circuit-breaker in this case (for example 230 V
AC). Motor-starter combinations consisting of PKE65 and contactors larger
than DILM38 can also be arranged together as motor starter combination on
a busbar adapter(BBA4L-63) or a top-hat rail adapter plate (PKZM4-XC55/2).
Table 16: Combination options
The PKE-SWD draws its energy for the communication electronics and for
controlling the LED from the SmartWire-DT network supply.
Please take into consideration the total power consumption of your Smart-
Wire-DT network and, if necessary, plan for an additional feeder module
EU5C-SWD-PF2-1.
PKE-XTUA-1.2 PKE-XTUA-4 PKE-XTUA-12 PKE-XTUA-32 PKE-XTUWA-32 PKE-XTUA-65
PKE12 ✓ ✓ ✓ X X X
PKE32
X X ✓ ✓ X X
PKE65
X X X X ✓ ✓
Application
Number of
PKE-SWD
Number of
PKE-SWD-32
Number of
DIL-SWD-32
Number of
EU5E-SWD-
4D2R
Electronic motor starter MSC-DEA
DOL starter (PKE and DILM) 0 1 0 0
Reversing starter (PKE and 2 x DILM)
0 1 1 0
Spatially separate arrangement
1)
DOL starters up to DILM38 1 0 1 0
DOL starters up to DILM38
1 0 0 1
Reversing starter up to DILM38
1 0 2 0
Reversing starter up to DILM38
1 0 0 1
1) Wiring sets PKZM0-XD(R)M12 and PKZM0-XD(R)M32 are not used
￫
For data for the current requirement please refer to the table in
the appendix on Page 253.
