Eaton SmartWire-DT SWD Series User Manual

6 PKE-SWD-CP, Connection for circuit-breaker PKE
6.10 Programming
154 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com
Object 4 [Index 4]:
Byte 0:
Object 5 [Index 5]:
Byte 0:
Object 6 [Index 6]:
Byte 0:
76543210
I-REL-L1 I-REL-L1 I-REL-L1 I-REL-L1 I-REL-L1 I-REL-L1 I-REL-L1 I-REL-L1
Data byte
Data bit Designation Description Notes
0 0-7 I-REL-L1 Relative phase
current L1 [%]
￫ Section
6.10.1.6, „Relative current
value (I-REL)“, page 149
76543210
I-REL-L2 I-REL-L2 I-REL-L2 I-REL-L2 I-REL-L2 I-REL-L2 I-REL-L2 I-REL-L2
Data byte Data bit Designation Description Notes
0 0-7 I-REL-L2 Relative phase
current L2 [%]
￫ Section
6.10.1.6, „Relative current
value (I-REL)“, page 149
76543210
I-REL-L3 I-REL-L3 I-REL-L3 I-REL-L3 I-REL-L3 I-REL-L3 I-REL-L3 I-REL-L3
Data byte
Data bit Designation Description Notes
0 0-7 I-REL-L3 Relative phase
current L3 [%]
￫ Section
6.10.1.6, „Relative current
value (I-REL)“, page 149
￫
For more information on the subject of acyclic data transfers,
consult the manuals
• SmartWire-DT gateway EU5C-SWD-DP, MN120001Z-DE,
• SmartWire-DT gateway EU5C-SWD-CAN, MN120002Z-DE,
• SmartWire-DT gateway EU5C-SWD-EIP-MODTCP,
MN120003Z-DE.
