7 Pilot devices M22-SWD…
7.2 M22-SWD front mount
SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com 171
Table 41: Flashing mark-to-space ratio settings
Byte 1 and byte 2:
The color is selected with R, G, B color components in the color space. The
red and blue components can be defined at any of 32 levels, the green com-
ponent at any of 64.
Bit 2 Bit 1 Mark-to-space ratio as a
percentage of the total signal
0 0 No flashing
0 1 50 / 50
1 0 25 / 75
1 1 75 / 25
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Red component Green component Blue component
