Eaton SmartWire-DT SWD Series User Manual

7 Pilot devices M22-SWD…
7.3 M22-SWD base fixing
SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com 197
Outputs
None
Diagnostics
In the event of a diagnosis the module reports the following error causes (0
is set for bit 4 in the input byte):
7.3.9.2 M22-SWD-KC22
The function element has one input byte at its disposal.
Input points
Byte 0:
76543210
SUBST PRSNT – DIAG – – NO1 NC1
numer-
ical
convert
er
Bit
Designation Description
0 NC1 = Normally Closed 0: contact actuated
1: contact not actuated
1
NO1 = Normally Open 0: contact not actuated
1: contact actuated
2
Not used –
3
Not used –
4
DIAG 0: no diagnostic alarm
1: Diagnosis present
5
Not used –
6
PRSNT 0: Module not available
1: Module available
7
SUBST 0: Configured module present
1: Universal module M22-SWD-NOP(C) present
Value
Description
0x10 The contact is in the middle position for longer than four
seconds.
0x11
Contact short-circuit
NO2
NC2
NO1
NC1
