11 Interface for NZM compact circuit-breakers
11.8 Programming
242 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com
11.8.1.7 Outputs
The data structure complies with the LVSG (Low Voltage Switchgear) profile
of PNO (PROFIBUS User Organization) which defines 2 bytes of output data.
All functions of the second byte are not supported. A dummy byte (byte 1) is
therefore required to ensure that the device is compatible with the LVSG pro-
file. An additional byte is provided for resetting the energy value.
22 1= I
2
t[A] activated
0=I
2
t[A] deactivated
23 Serial number NZM H byte
24 Serial number NZM M byte
25 Serial number NZM L byte
26 CB part no.
27 LS function
28 Main index, bit 7, 6 NZM firmware version
Secondary index 1, bit 5 - 3
Secondary index 2, bit 2 - 0
29 0 = NZM ground fault module not
present
29 16 = NZM ground fault module present
30 Reserve
Byte Dec.
value
Description Remark
Byte Bit Description Remark
7 6 5 4 3 2 1 0
0 0 0 Do not change status –
0 0 1 Switch off Switch command
0 1 0 Switch on Switch command
0 1 1 Do not change status –
1 Not used –
2
1 0 0 0 0 0 0 0 Reset power meter to zero Power meter
