Eaton SmartWire-DT SWD Series User Manual

13 Appendix
13.7 Technical data
SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com 263
Condensation
Storage °C –40 - 70 –40 - 70
Relative humidity, non-condensing (IEC/EN 60068-2-30) %
5 - 95 5 - 95
Supply voltage U
AUX
Rated operating voltage V 24 DC -15% +20%
Residual ripple of input voltage %
≦ 5 ≦ 5
Protection against polarity reversal
Yes Yes
max. current I
max
A 3 3
Short-circuit rating
no, external fuse FAZ Z3
Heat dissipation W
Normally 1 Normally 1
Potential isolation
no no
Rated operating voltage of 24-V-DC modules V
typical U
AUX
- 0.2 typical U
AUX
- 0.2
Supply voltage U
Pow
Specifications for connection to supply voltage V – 24 DC -15 % +
20 %
Residual ripple of input voltage %
– ≦ 5
Protection against polarity reversal
– Yes
rated operational current I A
– 0.7
Overload proof
– Yes
Inrush current and duration A
– 12.5 A/6 ms
Heat dissipation at 24 V DC W
– 3.8
Potential isolation between U
Pow
and 15 V SmartWire-DT supply
voltage
– Yes
Bridging voltage dips ms
– 10
Repetition rate s
– 1
status display LED
– Yes
SmartWire-DT supply voltage U
SWD
Rated operating voltage U
e
V 14.5 ± 3 % 14.5 ± 3 %
max. current I
max
A 0.7 0.7
Short-circuit rating
– Yes
Connection supply voltages
Connection type Push in terminals
solid
mm2
0.2 - 1.5 (AWG24 - 16)
Flexible with ferrule
mm2
0.25 - 1.5 0.25 - 1.5
System SmartWire-DT
Module type – –
Number of SmartWire-DT modules
– –
Baud Rate kbps
– –
Address allocation
– –
status display
– –
Porting
2 x plug, 8 pole
Plug connector
2 blade terminals SWD4-8MF2
EU5C-SWD-PF1-1 EU5C-SWD-PF2-1
