13 Appendix
13.7 Technical data
SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com 285
Connection Plug, 8-pole
Connection plug: External device plug SWD4-
8SF2-5
Device supply voltage
SWD module
U
SWD
V DC, (%) 14.5 (±3)
Current consumption at U
SWD
ï¿« Page 253
Connection supply and I/O
Connection type Push-In
solid
mm2
0.2 - 1.5 (AWG24 - AWG16)
flexible with ferrule
1) mm2
0.25 - 1.5
24 V DC supply for output supply
Rated operating voltage U
e
V –
Residual ripple of input voltage %
–
Protection against polarity reversal
–
1) Minimum length 8 mm
NZM-XSWD-704
Digital inputs
Qty. 2
Input current mA
normally 4 at 24 V DC
Voltage level to IEC/EN 61131-2
Limit value type 1 Low < 5 V DC; High > 15 V DC
Input delay
High ï¿« Low typ. < 0.2 ms
Low ï¿« High typ. < 0.2 ms
Status display inputs LED
yellow
Digital semiconductor outputs
Qty. 2
Output current A
0.2 at 24 V DC
Short-circuit detection threshold A
lamp load R
LL
W
Overload proof yes, with diagnostics
Switching capacity
EN 60947-5-1 utilization category
DC-13
Relay outputs
Qty. –
Contact type
–
c (contacts)
Utilization category AC-1, 250 V, 6 A –
Utilization category AC-15, 250 V, 3 A
–
Utilization category DC-13, 24 V, 1 A
–
Safe disconnection V AC
–
minimum load current mA
–
Response/reset time ms
–
Bounce duration ms
–
Short circuit protection
–
Status display outputs LED
–
Potential separation
Inputs for SmartWire-DT Yes
Semi-conductor outputs for SmartWire-DT
Yes
Semi-conductor outputs for inputs
–
Relays for SmartWire-DT
–
Relays for inputs
–
Relays for relays
–
NZM-XSWD-704
