Eaton SmartWire-DT SWD Series User Manual

2 I/O modules EU5E-SWD…
2.6 Digital module EU5E-SWD-8DX
28 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com
Byte 1:
2.6.7.2 Diagnostics
The module does not report a diagnosis.
Bit Designation Description
0 Not used –
1
Not used –
2
Not used –
3
Not used –
4
DIAG 0: no diagnostic alarm
1: Diagnostic alarm
5
Not used –
6
PRSNT 0: Module not available
1: Module available
7
SUBST 0: Configured module
present
1: universal module
M22-SWD-NOP(C) present
76543210
I7 I6 I5 I4 I3 I2 I1 I0
Bit
Designation Description
0 I0 Status input I0
1
I1 Status input I1
2
I2 Status input I2
3
I3 Status input I3
4
I4 Status input I4
5
I5 Status input I5
6
I6 Status input I6
7
I7 Status input I7
