Eaton SmartWire-DT SWD Series User Manual

2 I/O modules EU5E-SWD…
2.8 Digital module EU5E-SWD-4D4D
SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com 35
2.8.7.2 Outputs
Byte 0:
2.8.7.3 Diagnostics
In case of diagnosis, the module reports the following fault cause (bit 4 in
input byte 0 is set):
76543210
––––Q3Q2Q1Q0
Bit
Designation Description
0 Q0 Actuation output Q0
1
Q1 Actuation output Q1
2
Q2 Actuation output Q2
3
Q3 Actuation output Q3
4
Not used –
5
Not used –
6
Not used –
7
Not used –
Value Description
0x13 Short-circuit/overload on at least one output
