Eaton SmartWire-DT SWD Series User Manual

2 I/O modules EU5E-SWD…
2.12 Analog module EU5E-SWD-4AX
SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com 53
2.12.7.1 Input points
Byte 0:
The input resolution is 12-bit. The analog values are transmitted as unsigned
16-bit value.
Data addressing depends on the chosen programming system.
Input points
2.12.7.2 Diagnostics
In case of diagnosis, the module reports the following fault cause (bit 4 in
input byte 0 is set):
76543210
SUBST PRSNT – DIAG – – – –
Bit
Designation Description
0 Not used –
1
Not used –
2
Not used –
3
Not used –
4
DIAG 0: no diagnostic alarm
1: Diagnostic alarm
5
Not used –
6
PRSNT 0: Module not available
1: Module available
7
SUBST 0: Configured module present
1: universal module M22-SWD-
NOP(C) present
1514131211109876543210
IW0 ––––XXXXXXXXXXXX
IW1 ––––XXXXXXXXXXXX
IW2 ––––XXXXXXXXXXXX
IW3 ––––XXXXXXXXXXXX
Value Description
0x13 Overload on at least one analog current input (I > 23 mA)
