Eaton SmartWire-DT SWD Series User Manual

2 I/O modules EU5E-SWD…
2.13 Analog module EU5E-SWD-2A2A
58 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com
2.13.7.1 Input points
Byte 0:
The input resolution is 12-bit.The analog values are transmitted as unsigned
16-bit values.
Data addressing depends on the chosen programming system.
Input points
Outputs
2.13.7.2 Diagnostics
In case of diagnosis, the module reports the following fault cause (bit 4 in
input byte 0 is set):
76543210
SUBST PRSNT – DIAG – – – –
Bit
Designation Description
0 Not used –
1
Not used –
2
Not used –
3
Not used –
4
DIAG 0: no diagnostic alarm
1: Diagnostic alarm
5
Not used –
6
PRSNT 0: Module not available
1: Module available
7
SUBST 0: Configured module present
1: universal module M22-SWD-
NOP(C) present
1514131211109876543210
IW0 ––––XXXXXXXXXXXX
IW1 ––––XXXXXXXXXXXX
1514131211109876543210
QW0 ––––XXXXXXXXXXXX
QW1 ––––XXXXXXXXXXXX
Value Description
0x13 Short-circuit/overload on at least one analog output
0x13
Overload on at least one analog current input (I > 23 mA)
0x14
No 24 V DC supply voltage connected
