ECD WaveRIDER Series User Manual

WaveRIDER 129
5.6.4 Read WaveRIDER Data
The Read WaveRIDER Data command starts the data transfer process after completing
the data collection process.
To read WaveRIDER data:
1) Connect the M.O.L.E. to the PC (refer to the appropriate section in the Hardware
manual).
2) Select the Read WaveRIDER Data command from the WaveRIDER menu and a
status bar dialog box appears indicating that data retrieval from the M.O.L.E. has
begun.
Figure 5- 34: Read WaveRIDER Dialog Box
Once data transfer is complete, the dialog box will disappear and will return to the
current worksheet.
If the WaveRIDER has not collected enough data to create a complete profile a
message box appears (See Figure 5- 35).
Figure 5- 35: Communication Error Dialog box
The Read WaveRIDER Data command can be accessed on all worksheet Toolbars.
 Read WaveRIDER Data Button:
