ECD WaveRIDER Series - Channel Check Boxes

WaveRIDER 57
4.4.7 Channel Check Boxes
The Channel check boxes control whether the associated Data Plot is displayed on the
Data Graph and whether the data for that channel are included in the data table. To
view or remove a Data Plot, click the channel check box beside a sensor location
description to turn it “ON” or “OFF”.
Figure 4- 28: Channel Check Boxes
CHANNEL CHECK BOXES
