WaveRIDER 127
5.6.2 Set M.O.L.E. Clock
The M.O.L.E. has an internal clock it uses to identify the time and date of each data run
and to control when each measurement is recorded. The M.O.L.E. clock should be set
prior to data collection to ensure that the proper time was recorded.
Figure 5- 32: Set M.O.L.E. Clock Dialog Box
To set the M.O.L.E. clock:
1) Connect the M.O.L.E. to the PC (refer to the appropriate section in the Hardware
manual).
2) Select the Set M.O.L.E. Clock command from the WaveRIDER menu.
3) Enter the correct month, day, year, hour, minute, and second by adjusting the
slider(s) or manually typing in the corresponding text box.
When the Set Instrument Clock dialog box appears the current computer clock
setting is automatically entered in the text boxes.
4) Click the Send button to reset the clock.
When the setting of the clock is completed, a dialog box with the configuration data
appears.
To read the M.O.L.E. clock:
1) Connect the M.O.L.E. to the PC (refer to the appropriate section in the Hardware
manual).
2) Select the Set M.O.L.E. Clock command from the WaveRIDER menu.
3) Click the Read command button to display the current date and time from the
M.O.L.E.. If the clock is set wrong, the date or time will be incorrect.
