WaveRIDER 17
3.0 Operation
The following section will guide the user through a typical data collection process. These
steps may vary depending on the process your company uses.
Prior to data collection, the M.O.L.E. must be “WaveRIDER Ready” as indicated
by a “WaveRIDER Ready” or “Xpert” sticker on the front of the M.O.L.E..
3.1 Data Collection
1) To start collecting data, the width of the conveyor must be set to match the width
of the RIDER.
2) Set the solder wave, pre-heat temperatures and conveyor speed, as a common
product would be processed.
If the Wave solder machine has an in-line conveyor washer, it must be turned
“OFF” or the RIDER must be removed before it reaches the washer. Washing the
RIDER with the M.O.L.E. installed may cause damage.
