WaveRIDER 39
The Parameter Groups are defined as the following:
User Defined Parameter Group: These parameter columns can be used to
enter text to help identify the row with unique
information about that run (i.e. shift, operator,
line number, part number). This information will
also appear in the Tool Status box on the
Profile worksheet.
General Parameter Group: This group contains file information associated
with the run such as; date and time, (of profile)
and the data file tag.
Preheat Parameter Group: This group contains Pre-heat Temperature
Data.
M.O.L.E. Parameter Group: This group contains the physical condition of
the M.O.L.E. at the end of the run.
Chip Wave Parameter Group: This group contains the thermal and
mechanical data from the Chip Wave (first of
two waves).
Solder Wave Parameter Group: This group contains the thermal and
mechanical data from the Solder Wave.
Coupon Parameter Group: This group contains the coupon temperature,
and Slope data.
