52 WaveRIDER
4.4.5.1 Value Pop-up
Each value in the Data Table can be displayed as a Value Pop-up. A Value Pop-up is
graphically illustrated on the Data Graph showing how and where that value was
extracted from the profile.
Only one Value Pop-up can be displayed on the Data Graph at a time.
Figure 4- 23: Value Pop-up
To display a Value Pop-up:
1) Select the Profile worksheet.
2) Move the mouse cursor and pause over a desired value in the Data Table. That
value will automatically be displayed on the Data Graph where that value was
extracted.
The last displayed Value Pop-up will remain on the Data Graph until the user
selects a different worksheet.
VALUE POP-UP
SELECTED VALUE
