WaveRIDER 81
 LCL and UCL Cells
Lower and Upper control limits are automatically calculated from the Spreadsheet
parameter data and displayed on the SPC control charts when an SPC worksheet is
created. The LCL and UCL cells allow the user to override the calculated limits and
manually set them.
Figure 4- 47: User Specified Control Limits
USER
CONTROLLED
LCL & UCL
LCL & UCL
CELLS
