Edwards nEXT730D User Manual

Figure 6 Dimensional drawing for nEXT1230H
50
134.6
53
6
45°
45°
Ø
253
33.75°
4x90° = 360°
134.5
53
21
35
55
H
204
204
244
244
45
M6
4x
M8-14
X
4x M5-8
X
Ø A
3
1
2
4
5
DN 40 KF
Ø 124
Ø 213
BC-0033-B
All measurements indicated are shown in mm
1. PURGE G 1/8"
2. VENT G 1/8"
3. Water cooling for tube outer dia. 8 mm
4. 48 V d.c. power supply cable, 0.6 m long incl. plug
5. Control interface cable, 0.95 m long incl. plug
Table 6
Dimensions in mm
DN H A
nEXT1230H 200 CF 320.1 254
nEXT1230H 200 ISO-K 290.1 240
nEXT1230H 200 ISO-F 292.6 285
08/2021 - ©Edwards Limited
Page 28B8J200880_D
300812671_002_C3
