4.12 Mul-drop
operaon
Using mul‑drop mode, a single computer system can communicate with more than one
nEXT pump. Each nEXT pump must be assigned its own individual address before it can
be ed into a mul‑drop system. The command to assign the mul‑drop address is
sent in standard nEXT message format (as detailed in Assigning a mul-drop address on
page 73).
The message protocol in mul‑drop mode is marginally dierent to that described for
serial messages in single pump systems. The main dierences in mul‑drop message
protocol are detailed below:
▪ All mul‑drop commands, queries or replies have the rst character #.
▪ All commands, queries and replies contain a header containing the address of the
node that the message is to, followed by the address of the node that the message
is from.
▪ There is a delimiter character: (colon) which separates the two mul‑drop
addresses in the header.
▪ The remainder of the message (command, query or reply) follows the same
protocol as already described for single pump systems.
▪ The wild card address 99 is very useful and means 'any' node.
Aer a nEXT pump has been assigned a mul‑drop address, it will ignore any messages
in the format for single pumps. An individual nEXT pump will remain silent and ignore all
command messages unless the mul‑drop address matches its own address.
Figure 12 Conceptual diagram for mul-drop
connecon using RS232 interface
1. RS232 interface on control equipment 2. Buer
3. nEXT pump 4. OR gate
1. RS232 interface on control equipment 2. Buer
3. nEXT pump 4. OR gate
08/2021 - ©Edwards Limited
Page 46B8J200880_D
300812671_002_C3
