Edwards nEXT730D User Manual

Abbreviaon
Meaning
r
Returned error code - refer to Command set error c
o-
des on page 99
sp Space character
string May have several ASCII characters
X
Mul-drop decimal ASCII charact
er
§
*
Fields showing mulple d charact
ers are to indicate typical length. All data elds have
a maximum of 5 decimal characters (prexed by a minus number for negave numbers).
§
Fields showing mulple X characters are to indicate maximum length and not xed
length.
Typical seng command:
Command
! S 8 5 5 sp d d d cr
Typical seng r
eply:
R
eply
*
S 8 5 5 sp r cr
Typical query command:
Command
? S 8 5 5 cr
Typical query reply:
Reply
= S 8 5 5 sp d d d cr
6.1.3 Power limit seng
The pump is supplied with a def
ault power limit. If this limit is not suitable for the
applicaon, change it to any value between the maximum and minimum seng.
Table 17 Power limit seng
Maximum value set-
ting
Minimum value set-
ting
Default power set-
ting
nEXT730/930D 600 W 190 W 500 W
nEXT1230H 800 W 300 W 500 W
Send the command as follows (where the 'd' characters represent the value in Was
tha
t will be set. For example, to set the limit to 500 W, type 500).
Command
! S 8 5 5 sp d d d cr
The reply will be in the following format:
Reply
*
S 8 5 5 sp r cr
The Power Limit Seng is now stored in memory within the nEXT pump.
To check what power limit is set, send a query as follows:
Command
? S 8 5 5 cr
The reply will be in the following format:
08/2021 - ©Edwards Limited
Page 68B8J200880_D
300812671_002_C3
B8J200880_D - Congur
aon
