Edwards nEXT730D User Manual

6. Conguraon
Be
fore operang the pump, congure the motor controller sengs so that they are
suitable for the applicaon.
If the system is designed to operate with parallel control and monitoring, there is no
facility to change the majority of the motor controller sengs once the pump is installed
on the system.
The pump is supplied with all sengs at factory default values, as shown in Table:
Summary of commands that can be sent to the pump. If any of the motor controller
sengs are to be changed, change them before installing the pump on the system.
The pump can be congured using the customer serial comms over the serial interface.
Congure the pump using serial commands on page 66 details the commands that will
be needed to congure the motor controller. Alternavely use the Edwards TIC Turbo
and Instrument Controller, TIC Turbo Controller or TAG Controller. Further informaon
regarding this is detailed in Congure the pump using a TIC on page 74. The Edwards
nST2 PC soware can also be used to congure the pump, either via the serial interface
or via the USB service port.
Note:
The st
andby speed may be adjusted using the buon on the motor controller as
described in Standby speed seng on page 70.
If the pump is operated with parallel control and monitoring and the controller sengs
will not be recongured, go straight to Before starng the pump on page 75.
6.1 Congure the pump using serial commands
Refer to Table: Summary of commands that can be sent to the pump for a summary of
the full set of serial commands, parameter ranges and factory defaults for each seng.
Message structure on
page
67
The message structure and command set are the same for RS485 and
RS232 opons. To communicate a message to the nEXT pump, the charac-
ters must be sent in a specic order. If the message does not conform to the
correct structure it will be ignored and no reply will be sent.
Command and reply ta-
ble denions on page
67
Explanaon of the command and reply characters.
Power limit seng on
page 68
The pump is supplied with a default power limit. If this limit is not suitable
for the applicaon, change it to any value between the maximum and mini-
mum seng.
Powering a fan from the
motor controller on
page 69
A fan can be powered from the nEXT motor controller on auxiliary output 2.
Controlled venng op-
ons on page 69
If the motor controller is used to automacally control a vent valve, there
are a number of venng opons available.
08/2021 - ©Edwards Limited
Page 66B8J200880_D
300812671_002_C3
B8J200880_D - Conguraon
