Analyzer User Guide
To enable automated timing indicators:
1. To enable the automated timing measurement, place the mouse over any packet.
2. The time from one packet to the next and from the previous packet is indicated in grey text.
To make time measurements using the A-B cursors:
-
B cursors are especially useful when the two events being measured are
far apart
, such that one cursor can be set, then the user can scroll as needed
to the other event to set the second cursor.
1. Select the first desired location in the Instant Spectrum view.
2. Right click and select Place cursor A here.
The A cursor is placed at the location selected.
3. Select the second desired location in the Instant Spectrum view.
4. Right click and select Place cursor B here.
The B cursor is placed at the location selected, and timing information is provided, including
number of slots:
