C8 Maintenance 11. Replacing the Battery Unit
C Series Maintenance Manual Rev.2 397
3. Install the plate where the battery board is installed to.
Hexagon socket head cap bolts: 2-M4×10
Tightening torque: 4.0 ± 0.2 N·m
4. Connect the battery connectors.
5. Install the battery to the battery box.
6. Install the Arm #1 side cover.
For details, refer to C8 Maintenance: 3. Covers.
7. Perform the calibration.
For details, refer to C8 Maintenance: 16. Calibration.
To Next Page
